This black Corning UniCam Connector is easy to use and facilitates fast and simple installation. It is easily installed with the TLUC01. This connector requires little training and is perfect for field installations with both temporary and permanent applications. It is available with composite or zirconia ferrules.
For fiber-to-the-workstation applications where setup and teardown time are crucial, Corning UniCam LC connectors provide optical performance in a quick, simple field-termination solution. Fast and economical installation of fiber optic networks is made possible by high-precision mechanical splice technology. An LC, SC, or ST compliant connector can be installed in between 50 seconds and one minute.
The high-performance precision cleaver and lightweight, handheld installation tool completely removes human variability during installation, guaranteeing accurate terminations every time. From the installation tool's immediate go/no-go feedback signal showing proper mating of the cables to the cleaver's intuitive, hand-held precision design and dual-clamp precision hold, this package was created with network installers in mind. Installation is as simple as strip, clean, cleave, cam, and crimp, with excellent optical performance guaranteed.
Black LC Corning UniCam Connector Features
- Easy Installation
- Requires little training
- Used in both temporary and permanent installations
- Available with Composite or Zirconia ferrules
- Broad operating temperature range (-40°C to +75°C)
- Consistent optical performance
- Low installation cost, fast termination, and no consumables
- Minimum insertion loss, optimum optical performance
- RoHS Compliant
Black LC Corning UniCam Connector Specifications
- Nominal Fiber Outer Diameter: 125 µm
- Tensile Strength Jacketed Cable: 50 N
- Durability: ≤ 0.2 dB change, 500 rematings, FOTP-21
- Tensile Strength 900 µm Cable: 4.9 N (1.1 lb) change ≤ 0.2 dB, FOTP-6
Other Corning UniCam Connectors Available:
- SC - 62.5 µm Multimode (OM1)
- SC/UPC - 62.5 µm Multimode (OM1)
- SC - 50 µm Multimode (OM2)
- SC - Singlemode (OS2)
- SC/APC - Singlemode (OS2)
- ST - 62.5 µm Multimode (OM1)
- ST - 50 µm Multimode (OM2)
- ST - Singlemode (OS2)
- LC - 62.5 µm Multimode (OM1)
- LC - 50 µm Multimode (OM2)
- LC - 50 µm Multimode (OM3/OM4)
- LC - Singlemode (OS2)
