Gigabit Media Converter, Single-mode SC, 20km

1000BASE-TX to 1000BASE-FX
Item No: EMC-2100S20
MFG Part#: EMC-2100S20
7 In Stock
Manufacturer: Fibertronics
$202.50

This Gigabit media converter supports two types of media for network connections such as 1000Base-T and 1000Base-SX/LX fiber. The media converter is used to convert one type media signal to other equivalent type, this allows the two segments to be connected easily and inexpensively. The Converter can be used as a standalone unit or as a slide-in module to the 19" converter rack (up to 16 units) for use at a central wiring hub.





Product Features

  • Easy Intergration
  • Cost Effective
  • Auto MDI/MDI-X support on RJ-45 Port
  • Auto polarity correction on RJ-45 Port
  • Local and Remote loopback test for the first time installation and troubleshooting
  • Compatible with other Gigabit 1000Base-T/SX/LX devices
  • Status LEDs for easy monitoring of device status
  • Compliant with IEEE802.3ab 1000Base-T and IEEE 802.3z Base-SX/LX Standards
  • FCC Class A & CE approved

This Gigabit media converter supports two types of media for network connections such as 1000Base-T and 1000Base-SX/LX fiber. The media converter is used to convert one type media signal to other equivalent type, this allows the two segments to be connected easily and inexpensively. The Converter can be used as a standalone unit or as a slide-in module to the 19" converter rack (up to 16 units) for use at a central wiring hub.





Product Features

  • Easy Intergration
  • Cost Effective
  • Auto MDI/MDI-X support on RJ-45 Port
  • Auto polarity correction on RJ-45 Port
  • Local and Remote loopback test for the first time installation and troubleshooting
  • Compatible with other Gigabit 1000Base-T/SX/LX devices
  • Status LEDs for easy monitoring of device status
  • Compliant with IEEE802.3ab 1000Base-T and IEEE 802.3z Base-SX/LX Standards
  • FCC Class A & CE approved
Products specifications
Connector SC/UPC
Mode Single-mode, OS2, 9/125
Maximum Distance 20km Single-mode
Input Power 2A +5V, Comes with 115V Adapter
Operating Temperature 0 ~ 70°C
Height 26.2mm
Width 81mm
Depth 105mm
Write your own review
  • Only registered users can write reviews
  • Bad
  • Excellent
Products specifications
Connector SC/UPC
Mode Single-mode, OS2, 9/125
Maximum Distance 20km Single-mode
Input Power 2A +5V, Comes with 115V Adapter
Operating Temperature 0 ~ 70°C
Height 26.2mm
Width 81mm
Depth 105mm
